    Esoteric – G25u word clock and up converter in silver

    $1,250.00

    The G-25U is a hybrid “PCM digital audio up converter” and a ‘master clock generator’. As a D/D converter, it can convert digital audio frequencies from red book CD standards all the way up to 192 kHz, improving sound quality by over sampling and re-timing a PCM digital audio data stream. As a master clock generator, it can process word clock signals by its internal, high precision crystal oscillator. This master clock is accurate to +/- 1ppm. (Measured as 1 part per million. Most conventional CD/DVD devices are accurate to +/- 10-50 ppm).



    MAIN SPECIFICATIONS

    Output Frequency Accuracy: ±1ppm (Factory default)

    Digital Input and Output Terminals for PCM Audio up Conversion or digital re- clocking/re-timing:
    Output Terminals: x4 (XLR1, XLR2, RCA, OPTICAL)
    XLR1 and XLR2 can be used in dual mode.

    Output Signals: S/PDIF, AES3 DUAL
    Input Terminals: x3 (RCA1, RCA2, OPTICAL)
    Input Signals: S/PDIF
    WORD CLOCK terminals
    Output Terminals: x3 (BNC: A/B/C)
    Output Signals: TTL level/75Ω
    External Synchronization Input Terminal: x1 (BNC)
    Input Signal: 1.4 5Vp-p/75Ω (44.1/48/88.2/96/176.4/192kHz/10MHz)
    AC Power: 100V/120V/230V AC, 50-60Hz
    Power Consumption: 9W
    Dimensions (W x H x D): 442mm x 96mm x 359mm (17.5” x 3 .77” x 14.1”)

    Weight: 7.9kg (17.5 pounds)
