Parasound JC-2 Differentially Balanced ClassA Preamplifier in Silver
$2,000.00
- 6 pairs unbalanced RCA line-level audio input jacks
- 2 input pairs can be switched to XLR balanced connectors
- Independent balanced/unbalanced select for the L & R channel
- Each channel’s input is switched by its own gold-on-silver contact relay
- 4 output jack pairs with specialized functions:
- 1 Main output jack pair is balanced XLR, polarity is switched by remote
- 1 Main output jack pair is unbalanced RCA, polarity is switched by remote
- 1 output jack pair is unbalanced RCA, inverted polarity only
- 1 output pair is unbalanced RCA, normal polarity, fixed level for recorders
- Dual-mono left & right channel circuit boards minimize crosstalk
- Hand-matched complementary FETs
- Direct DC servo-coupled, no capacitors in the signal path
- Premium 4-gang motor-driven analog master volume control
- Separate TKD brand analog gain controls for L & R channel
- 3/8″ thick aluminum shielding around audio boards
- Shielding prevents noise from power supplies & control circuits
- Separate output jacks for simultaneous normal & non-inverting polarity
- Aluminum chassis rear panel
- Remote control polarity switching uses gold-on-silver contact relays
- Vampire brand 24k gold-plated RCA jacks
- Neutrik brand premium XLR connectors
- Canare brand internal wiring
- High capacity R-core audio power transformer & inductor
- Hyper-fast soft recovery audio bridge rectifiers diodes
- Independent power supply for controller, relay coils, triggers, LEDs
- Remote control handset controls all functions
- Discrete IR codes for remote control
- Four 12v trigger output jacks for power amp auto turn-on:
- Two 12v trigger jacks are switched by the remote handset
- Two 12v trigger jacks are live when the JC 2 is turned on
- Two-way RS-232 serial port connection
- Line level inputs only; no inputs for phono
- Audio mute is switched by independent L & R relays
- Rear panel IR repeater input & loop out jacks
- Premium detachable heavy gauge IEC AC cord
- 2 6′ (2m) trigger wires included
- Remote handset also controls Parasound Halo T 3 Tuner
- 3u Chassis, rack mountable with HRA3 (sold separately5 Hz – 100 kHz, +0/-3 dB
- Distortion THD: < 0.003% at 100 Hz THD: < 0.005% at 20 kHz
- S/N Ratio > 116 dB, input shorted, IHF A-weighted > 104 dB, input shorted, unweighted
- Crosstalk > 100 dB at 10 kHz. > 90 dB at 20 kHz. Gain. 14 dB, maximum.
- L, R Gain Control Range. – 10 dB
- Input Impedance. Unbalanced: 30k ohms. Balanced: 30k ohms per leg.
- Output Impedance Unbalanced: < 60 ohms. Balanced: < 60 ohms per leg.
- Input Sensitivity 200 mV for 1 V output. Total Gain: 14 dB. Maximum Output: 8 V
- AC Power Requirement 110 – 120 V or 220-240 V, 50 – 60 Hzs (switch on rear panel)17 1/4″ X 16″ X 5 7/8″ Net: 24 lbs. Shipping: 36 lbs. Rack Mount HRA 3 available
